Support operating system: Windows 7, Windows NT, Windows 2000,Windows XP, VISTA
-
High refresh rate and high sampling rate
-
Memory depth: 1Mbytle/channel
-
Built-in Fast Fourier Transform function(FFT)
-
20 Automatic measurements
-
Automatic cursor tracking measurements
-
Fast selectable offset calibration
-
Add, Subtract , Multiply and Division Mathematic Functions
-
Waveform storage, adjustable waveform intensity and more effective waveform view
-
Several user-selectable languages
-
Waveform can be saved as EXCEL, BMP, JPG based on the time and voltage
Hantek 6022BE is a high cost-effective digital storage oscilloscope with the bandwidth 20MHz, 2 channels, sample rate 48MS/s and dual probes. It is a good industrial design, which has the anodic aluminum oxide shell. It improves the aluminum alloy surface hardness and has good heat resistance and abrasion resistance. It comes with the USB(TM) cord that can be easily inserted into the USB chassis.
Specifications:
Item |
Hantek 6022BE |
Bandwidth |
20MHz |
Channel |
2 channels |
Maximum Real-time Sample Rate |
48MS/s |
Storage Depth |
1M |
Vertical Resolution |
8Bit |
Impedance |
1MΩ 25pF |
Coupling |
DC |
Voltage range |
20mV-5V, 8Steps |
DC Vertical Accuracy |
±3% |
Time Base Range |
1ns-5000s, 39 Steps |
Adjustable Vertical Position |
Yes |
Input Protection |
Diode clamped |
X-Y |
Yes |
Horizontal |
Automatic, standard and single |
Trigger Slope |
+/- |
Adjustable Trigger level |
Yes |
Trigger Source |
CH1, CH2 |
Pretrigger |
0-100% |
Sampling Rate Choice |
Yes |
Fai Line Shows |
Dot/line, intensity control |
Network |
On/off |
Cursor Measurement |
Yes |
Arithmetic |
Quick fourier transform, reverse, add, subtract, multiply and divide |
Package Includes:
-
1 x Hantek 6022BE USB Digital Storage Oscilloscope
-
1 x USB Cable
-
2 x Oscilloscope probes
-
1 x Disc
