Universal Adjustable BGA Reballing Station Base Holder + 10pcs 90*90mm Magnet Stencil

 Universal Adjustable BGA Reballing Station Base Holder + 10pcs 90*90mm Magnet Stencil

Applications

Universal Adjustable BGA Solder Base Holder

new self-locking BGA reballing station, made of Aluminum alloy structure

with automatic centering function, rotating spiral disk, four folders block locking chips without a single adjustment

positioning accuracy standards, clamping speed, high efficiency!

Stencil dimensions: 80*80mm and 90*90mm

Advantages:

1. For both 80mm and 90mm stencils

2. No need use wrench to adjust the height, just use finger up and down

3. Suitable for rectangle chips, and very small chip 4*4mm, maximum chip 45*45mm

4. High precision for adjusting the chip, magnet inside, auto fix, more fast and convenient .

Simultaneous Adjustment on 4 Sides

Auto Locking

Accurate Position

Easy Operation

Rotator

Compatible with 80mm and 90mm Stencils

90*90mm  Stencil list 10PCS

Universal stencil for 0.3mm ball, pitch 0.58mm (90*90mm)

Universal stencil for 0.35mm ball, pitch 0.65mm (90*90mm)

Universal stencil for 0.4mm ball, pitch 0.7mm (90*90mm)

Universal stencil for 0.45mm ball, pitch 0.78mm (90*90mm)

Universal stencil for 0.5mm ball, pitch 0.8mm (90*90mm)

Universal stencil for 0.55mm ball, pitch 1.02mm (90*90mm)

Universal stencil for 0.6mm ball, pitch 0.9mm (90*90mm)

Universal stencil for 0.6mm ball, pitch 1.0mm (90*90mm)

Universal stencil for 0.6mm ball, pitch 1.1mm (90*90mm)

Universal stencil for 0.76mm ball, pitch 1.27mm (90*90mm)

Packing List:

1pcs  BGA reballing station

10pcs 90*90mm Stencils
